Matrix paging system ( MatriMix )
Matrix system allows the user with flexibility of routing desired input source to the destination with ease. The applications includes restaurants, hotels, offices and other larger venues such as theme parks, airports, bus terminals etc.
​
It is also a device for uninterrupted paging setup, where paging on certain zones would not affect the BGM being broadcasted to another zones.
​
Amperes's MxP2288 MatriMix System, which is currently the 3 rd generation of Matrix considers all aspects required for a truly user friendly product and comes with safety features too, such as device failure emergency paging bypass.
Matrix Introduction PPT
Model Listing
MxP2288
12 x 8 Matrix Controller with LAN Interface
​With its 12 inputs, they can be cascaded to form more output zones and the cascading works has been made simpler. Controls can be performed at front button or easier way is to link the unit to LAN or WIFI to enable controls via smartphone, tablet or from the desktop PC. ​
​
Another unique and important identity is its fail safe feature which would still allow emergency paging via EP1200 panel if the unit fails digitally or unintentionally shut down.
​
MxP2288 is suitable for small to medium scale installations such as high end residential, hotels, restaurants, club house, etc.
RP1104
Touch Screen Matrix Remote Control Panel
The wall panel remote touch screen controller can be installed at designated zone to control the source and volume selection at the particular area, or to be used as a master controller for all output zones of matrix controller.
​
The panels are cabled to controller using 4 core screen cable and they can be installed in daisy chain method.
PD1160
Matrix Paging Mic (8/16 Zone Paging Mic)
PD1160 is designed particularly for application with MxP2288, with 8 / 16 zone controls. It fits the need for a simple paging console and able to control two units of MxP in cascade.
​
Other models of PD series can be used to link with MxP if the installation zones are larger such as PD2800, PD1900 or PD1240.
​
See alternative at Paging Mic section.
EX1103
Paging Mic Extender
EX1103 shall be used when there are more than one paging mic to be used with MxP controller. Each mic shall be connected with EX1103 in a loop and at the end, plug it to the mic input port of the controller.
​
It is an optional item only required in multi point paging setup.
MM8804
8 x 4 DSP Matrix Controller
MM8804 is a new matrix mixer / controller designed to cater for installation such as place of worships (mosques, churches etc.), club house, restaurant etc., in which the user needs flexibility to mix incoming sources and broadcast to different areas with different settings of audio characteristics.
​
Example, a mosque with various types of speakers (column, horns) with various locations within the building will need audio calibration for types of speakers, acoustic environment and the needs for delay.
