MA2000 / MA2000P Series

Mixer Amplifier with Zone Selector (Class D)

MA2000 Series is a compact Class D mixing amplifier with 6-zone control and optional media player, ideal for small installations like showrooms, offices, and prayer halls.

Class D amplification for high efficiency and sound quality

Supports zone paging with PM1060 mic

Available in 120W, 240W & 360W with 100V and 4 Ohm speaker outputs

Small and lightweight for easy installation

Introduction

MA2000 / MA2000P Series is a newly enhanced range of Class D mixing amplifiers offering improved sound quality, lower heat output, and a compact, lightweight design. Available in 60W, 120W, 240W, and 360W (100V line), they are perfect for small to medium-scale PA installations.

Equipped with 6-zone output selectors, the MA2000 series supports direct connection to the PM1060 paging microphone for zone paging. It also includes DC backup input for uninterrupted operation.


Two versions are available:

  • MA20XX – Standard model with zone control

  • MA20XXP – Includes built-in media player (USB, SD, Bluetooth, FM tuner)

Series model variants:

  • MA2012 / MA2012P: 120W 100V Line

  • MA2024 / MA2024P:  240W 100V Line

  • MA2036 / MA2036P: 360W 100V Line


Ideal for venues such as boutiques, showrooms, offices, prayer halls, and meeting rooms, the MA2000 Series delivers flexibility, efficiency, and clear audio in a space-saving form.


Packing information

  • Carton size : 555 (L) x 295 (W) x 165 (H) mm

  • Gross weight : MC21XX: 4.45 kg / MC21XXP: 4.5 kg

  • 1 unit(s) per carton

  • Introduction

    MA2000 / MA2000P Series is a newly enhanced range of Class D mixing amplifiers offering improved sound quality, lower heat output, and a compact, lightweight design. Available in 60W, 120W, 240W, and 360W (100V line), they are perfect for small to medium-scale PA installations.

    Equipped with 6-zone output selectors, the MA2000 series supports direct connection to the PM1060 paging microphone for zone paging. It also includes DC backup input for uninterrupted operation.


    Two versions are available:

    • MA20XX – Standard model with zone control

    • MA20XXP – Includes built-in media player (USB, SD, Bluetooth, FM tuner)

    Series model variants:

    • MA2012 / MA2012P: 120W 100V Line

    • MA2024 / MA2024P:  240W 100V Line

    • MA2036 / MA2036P: 360W 100V Line


    Ideal for venues such as boutiques, showrooms, offices, prayer halls, and meeting rooms, the MA2000 Series delivers flexibility, efficiency, and clear audio in a space-saving form.


    Packing information

    • Carton size : 555 (L) x 295 (W) x 165 (H) mm

    • Gross weight : MC21XX: 4.45 kg / MC21XXP: 4.5 kg

    • 1 unit(s) per carton


  • MA2000 Series


    MA2012 / 2012P

    MA2024 / 2024P

    MA2036 / 2036P

    Power requirements




    Power rating (rms)

    120W 100V line

    240W 100V line

    360W 100V line

    Operating voltage

    220 - 240V AC

    220 - 240V AC

    220 - 240V AC

    Power consumption

    160W / 0.7A

    285W / 1.2A

    450W / 1.9A

    Input, output & control




    Input - Ch 1 and 2

    Balanced Mic input with 12V Phantom Power (10k Ohm) ; Adjustable mute priority

    Balanced Mic input with 12V Phantom Power (10k Ohm) ; Adjustable mute priority

    Balanced Mic input with 12V Phantom Power (10k Ohm) ; Adjustable mute priority

             - Ch 3 and 4

    Balanced Mic / Line selectable with 12V Phantom Power (Mic : 10k Ohm, Line : 15k Ohm)

    Balanced Mic / Line selectable with 12V Phantom Power (Mic : 10k Ohm, Line : 15k Ohm)

    Balanced Mic / Line selectable with 12V Phantom Power (Mic : 10k Ohm, Line : 15k Ohm)

             - Ch 5 and 6

    Unbalanced input (15k Ohm) RCA 0 dBV

    Unbalanced input (15k Ohm) RCA 0 dBV

    Unbalanced input (15k Ohm) RCA 0 dBV

    THD + N

    <1%

    <1%

    <1%

    S/N ratio

    >68 dB

    >68 dB

    >68 dB

    Tone controls

    Bass (100 Hz), Treble (10 kHz) +/- 15 dB

    Bass (100 Hz), Treble (10 kHz) +/- 15 dB

    Bass (100 Hz), Treble (10 kHz) +/- 15 dB

    Frequency response

    120 - 20 kHz (+/- 3 dB)

    120 - 20 kHz (+/- 3 dB)

    120 - 20 kHz (+/- 3 dB)

    Signal output

    0 dBU balanced line

    0 dBU balanced line

    0 dBU balanced line

    Zone output

    6 zone : Front switch and remote paging mic with All Call

    6 zone : Front switch and remote paging mic with All Call

    6 zone : Front switch and remote paging mic with All Call

    Power output - 4 Ohm @ 1V rms input 100V @ 1V rms input

    50V rms 100V rms

    50V rms 100V rms

    50V rms 100V rms

    Protections

    Thermal, short circuit, AC and DC fuses

    Thermal, short circuit, AC and DC fuses

    Thermal, short circuit, AC and DC fuses

    Indicators

    Power, zone selection, signal level

    Power, zone selection, signal level

    Power, zone selection, signal level

    Cooling system

    Thermostat controlled fan at 45°C

    Thermostat controlled fan at 45°C

    Thermostat controlled fan at 45°C

    Case




    Dimensions (W x H x D)

    434 x 88 x 200 mm (without bracket)

    434 x 88 x 200 mm (without bracket)

    434 x 88 x 200 mm (without bracket)

    Weight

    4.35 kg / 4.40 kg (P version)

    4.35 kg / 4.40 kg (P version)

    4.35 kg / 4.40 kg (P version)

    Note: The specification parameters may be changed, added, or omitted without prior notice.

    • Available in 60W, 120W, 240W, and 360W (100V line output)

    • High-efficiency Class D amplification with 100V and 4 Ohm speaker outputs for better sound and lower heat

    • 6 input channels with front-panel mic jack and phantom power

    • 6-zone speaker output with zone selector, All Call and remote trigger port

    • Priority muting for Mic Input 1 with adjustable muting level

    • Supports zone paging with PM1060 microphone

    • DC backup input for uninterrupted operation

    • Optional media player with USB, SD, Bluetooth, and FM tuner (MA20XXP models)

    • Independent bass and treble tone controls

    • Runs on AC and DC opreation for uninterrupted operation during power failure

    • Compact and lightweight for easy installation

    • Suitable for small venues like offices, showrooms, and prayer halls
