iHS8020
20W IP PoE ABS Horn Speaker
iHS8020 is a 20W PoE horn speaker with a 2” compression driver, perfect for outdoor use in Amperes IP PA systems, offering easy installation and reduced wiring with PoE and Class D amplification.
Clear sound with 2" compression coil driver
Remote configuration via Amperes PMX Software
Waterproof RJ45 connectors
Energy-efficient Class D amplifier
Introduction
iHS8020 is a 20W IP PoE horn speaker designed for decentralized setups in Amperes IP / Network PA systems. It features a 2” compression coil driver with an ABS flare, powered by PoE and amplified using a Class D amplifier. Suitable for outdoor areas such as car parks, it includes waterproof RJ45 connectors for reliable performance.
About Amperes IP Speakers
Amperes IP Speakers offer a convenient solution for placing speakers wherever background music (BGM) or paging is needed in an IP-based PA system. They eliminate the need for home-run cabling, saving on installation costs—as long as a network port is available nearby.
Available in four models—full range, ceiling, pendant, and horn—these speakers are all powered by PoE and built with Class D amplifiers. These speakers work seamlessly with Amperes iPX systems, receiving audio from PMX software or iPX5200 MK II server, and support paging via iPD/iEP microphones or PMX software.
Packing information
Carton size : 590 (L) x 455 (W) x 615 (H) mm
Nett weight: 15.20 kg
Gross weight : 16.50 kg
8 unit(s) per carton
*Loose box information will be provided upon request
Introduction
iHS8020 is a 20W IP PoE horn speaker designed for decentralized setups in Amperes IP / Network PA systems. It features a 2” compression coil driver with an ABS flare, powered by PoE and amplified using a Class D amplifier. Suitable for outdoor areas such as car parks, it includes waterproof RJ45 connectors for reliable performance.
About Amperes IP Speakers
Amperes IP Speakers offer a convenient solution for placing speakers wherever background music (BGM) or paging is needed in an IP-based PA system. They eliminate the need for home-run cabling, saving on installation costs—as long as a network port is available nearby.
Available in four models—full range, ceiling, pendant, and horn—these speakers are all powered by PoE and built with Class D amplifiers. These speakers work seamlessly with Amperes iPX systems, receiving audio from PMX software or iPX5200 MK II server, and support paging via iPD/iEP microphones or PMX software.
Packing information
Carton size : 590 (L) x 455 (W) x 615 (H) mm
Nett weight: 15.20 kg
Gross weight : 16.50 kg
8 unit(s) per carton
*Loose box information will be provided upon request
iHS8020 - Kindly zoom to view (Desktop)
Power Requirements
Power rating
20W
Power source
PoE+ (IEEE 802.3 at 48V)
Standby power consumptions
0.5W
Operating power consumptions
15W Max
Connectivity / Communications
Amplifier rating
20W @ 4Ω
Speaker type
Compression driver
Speaker drive diameter
2” (50mm)
Sensitivity @ 1kHz / W / m
92dB
Frequency response
200Hz – 8kHz (±3dB)
S/N ratio
85dB
Audio codec
IMA ADPCM / MP3 / WAV
Network & protocols
100Base-T / TCP/IP, UDP, IGMP, HTTP, ADMP, ADP
User interface
Web browser interface (Google Chrome preferred, IE V8+ supported)
Firmware update
Via web browser
Priority controls
Paging over BGM
Operating Conditions
Operating temperature
0°C to 70°C
Relative humidity
<70%
Physical Dimensions & Weight
Dimensions (W x H x D)
293 x 212 x 290 mm
Weight (kg)
1.80 kg
Housing
ABS
Color
White
Note: The specification parameters may be changed, added, or omitted without prior notice. Last updated on 9 Oct 2025.
2" Compression coil driver speaker for clear and focused sound reproduction
ABS Flare
Easy setup with PoE power
Remote configuration available via Amperes PMX Software
Automatically mutes BGM during paging
Built-in energy-saving Class D amplifier
Includes waterproof RJ45 connectors
Suitable for outdoor areas such as car parks
