BC9740

24V DC Automatic Battery Charger

BC9740 is a 24V DC, 4A charger for SLA batteries up to 100Ah, with smart charging, built-in protection, and RS485 monitoring for extended battery life.

  • 4A constant voltage charging with automatic current reduction

  • Built-in surge and short circuit protection

  • Thermal sensors with auto shutdown to prevent overheating

  • Reverse polarity protection to prevent battery damage

Introduction

BC9740 is a microprocessor-based 24V DC battery charger with a 4A capacity battery, designed for SLA batteries up to 100Ah. Engineered for efficiency, it features intelligent charge control, built-in reverse polarity protection and monitoring circuit to extend battery life.

With RS485 data output for remote monitoring and an LCD status display, it ensures easy operation and real-time status updates. Ideal for PA system backup power, the BC9740 offers compact design, efficient charging, and remote monitoring capabilities via PMX III, making it a reliable choice for uninterrupted power solutions.

Packing information

  • Carton size: 555 (L) x 295 (W) x 95 (H) mm

  • Gross weight: 5.20 kg

  • 1 unit(s) per carton

  • Introduction

    BC9740 is a microprocessor-based 24V DC battery charger with a 4A capacity battery, designed for SLA batteries up to 100Ah. Engineered for efficiency, it features intelligent charge control, built-in reverse polarity protection and monitoring circuit to extend battery life.

    With RS485 data output for remote monitoring and an LCD status display, it ensures easy operation and real-time status updates. Ideal for PA system backup power, the BC9740 offers compact design, efficient charging, and remote monitoring capabilities via PMX III, making it a reliable choice for uninterrupted power solutions.

    Packing information

    • Carton size: 555 (L) x 295 (W) x 95 (H) mm​

    • Gross weight: 5.20 kg

    • 1 unit(s) per carton


  • BC9740

    Power requirements


    Operating voltage

    220 - 240V AC

    Charging voltage

    27.8V DC

    Charging current

    4A ; (max 5A)

    Idle power consumption

    1.3W

    Protections, displays, & communication


    Protections

    Low battery audio disconnection, reverse polarity, short circuit

    Indicators

    AC mains, short circuit and low battery

    Displays

    Charging current Charging voltage Battery voltage Output current Battery reverse polarity

    Communication

    RS485 out ; link to Amperes PMX III via iPX5500 communication box for remote monitoring

    E/M back up Amp rating

    25A max (Use external contractor / relay if required)

    Terminals

    Battery input, EM load

    Case


    Dimensions (W x H x D)

    482 x 44 x 180 mm

    Weight

    4.50kg

    Note: The specification parameters may be changed, added, or omitted without prior notice.

    • 4A constant voltage charging with automatic current reduction

    • Low battery disconnection alert to extend battery lifespan

    • RS485 port for remote monitoring via Amperes PMX III Software and Amperes iPX5500 Communication Box

    • Supports 24V battery banks with stable DC voltage charging

    • Built-in surge and short circuit protection

    • Thermal sensors with automatic shutdown to prevent overheating

    • Reverse polarity protection to prevent battery damage

  • Catalogue

    File Type: PDF

    Version: Year 24/25

    Instruction Manual

    File Type: PDF

    Version: V6 (09/23)

    AutoCAD

    File Type: DWG

    Version: -

    CE Marking

    File Type: PDF

    Year: 2022

Cross references

PMX III

IP-based PA management software for Amperes iPX System with BGM streaming, zone management, and PC paging. Available in Standard and Premium versions.
